Gun-Guides AK-47 – Gun Guides

Easy to use -- Comb binding lies open and flat on your work surface.

16 pages & 20 + high-resolution grayscale images.

Cardstock cover. Bright white paper.

The only current printed manual that includes information on ALL models.

Guide includes Introduction, Disassembly, Reassembly, and Accessories.

Introduction:
Brief history of the AK-47 Assault Rifle

It has been estimated that the worldwide production of the AK-47 rifle, and its variants has exceeded over 90 million. The AK has been licensed (and copied) in dozens of countries. Even after nearly 60 years, it is still the weapon of choice for soldiers, law enforcement, and the gun enthusiast.

Mikhail T. Kalashnikov, a Soviet Engineer, designed the weapon in the late 40’s and it was adopted by the Soviet Army in 1949 as the officially designated “7.62mm Automat Kalashnikova, obraztsa 1947 goda” (7.62mm Kalashnikov automatic rifle, model of 1947). The weapon went into service in 1951.

The AK-47 and AKM (AK Modified) fire a 7.62 x 39-mm (M1943) ammo which is a heavy caliber small arms round capable of defeating most body armor. The weapon is usually equipped with 30 round magazines and is available in a fixed wooden or folding stock (AKS). The AKM has a stamped receiver and entered into service in 1961. The AK-74 fires a 5.45 mm bullet and has replaced many of the 7.62 weapons. All models are gas operated with a rotating bolt feed system.

The semiautomatic version has a “practical” rate of fire of 40 rounds per minute. The AK has an “effective” range of about 300 meters. (328 yards). This is due to its bulky bullet traveling at only 2,300 feet per second. Average weight: 9.5 Pounds. Overall length is 34.2 inches. Folded length: 27.5 Inches.

Safety First
Exploded Parts Diagrams
Parts List

Disassembly:
-Magazine
-Clear Weapon
-Receiver Cover
-Recoil Guide & Spring
-Bolt Carrier & Assemblies
-Upper Forearm & Gas Tube
-Lower Forearm
-Bolt
-Firing Pin
-Extractor
-Safety
-Hammer Spring TIP
-Hammer/Trigger Retainer
-Trigger
-Hammer
-Magazine

Reassembly:
Bolt
Extractor
Firing Pin

Accessories
